Westerbeke Marine 35C / 35D / 35E (3 Cyl) Diesel Engine Service Parts

Service Parts for Westerbeke Diesel Marine (3 Cylinder) Engine Model

35C3 - 29 Hp @3600 Rpm

35D3 - 31 Hp @ 3000 Rpm

35E3 - 28 Hp @ 3000 Rpm

Download Parts Manual -

Basic Service Parts	Part Number	Remarks
Lub Oil Filter	036918
Fuel filter element	030200
In In-line fuel filter on the lift pump	048076
Air filter element	039705
Zinc Anode	011885
Heat Exchanger Brass End Cap	022850
GASKET, EXCHANGER 2.75"	022851	Need Qty 2
O-Ring H Exchanger GSK	019321	Need Qty 2
Impeller seawater pump	048500
BELT, STD 12V50A Alt	045232
Belt
Optional Svc Kits
Parts Kit A	046420
Parts Kit B	047157	Special order in
Hose kit	048973
Cooling System
Thermostat	024688
Thermostat Gasket	034196
Raw Water pump	048080	SS fm 033636 pump
Raw Water Pump 048080 Repair Kit	049000	For the New Pump
Raw Water pump 033636 Repair Kit;	034466	Kit for old-style pump
Circulation Coolant Pump	045231
Cir Pump Gasket	030474
Coolant Filler Cap	024306
Heat Exchanger - STD Copper	036899
Heat Exchanger - Copper Nickel - HD		AFM MRC36899CN
Exhaust Mixing Elbow Kit-45Dig	037402
DC/AC Electrical Items
Starter Motor- 12V	030593
DC Alternator -12V -50 Amp	043953 / 055417	Mitsubishi
Fuel Lift Pump 12V -STD	039275
Fuel Stop Solenoid 12V	037100	3-wire Type
Glow Plug Preheat 12V	024353
Breaker Cir 10AMP	036563
Breaker 20Amp 12v Rest push	024683
Relay K1/2 - 12V 40A	037833
Senders/ Switches/ Solenoids 12v
Oil Press Switch Nomaly Open -STD	037323
Oil Press Sender for Gauge	024132	100 PSI 12V
Temp Switch - Alarm	056519	SS fm 030125 old P/N
Temp Sender for Gauge	035109
Exhaust Temp switch - Alarm	032923
Pre-heat / Start solenoid	024639

Eng/ Mount Isolator Front/ Rear	040510	Qty 4

Optional - None Westerbeke Assorted mounts		Ref MES Mount
